Schneider Electric Tesys u standard control unit luca - class 10 - 0.35...1.4 a - 24 v dc (3389110363821)

TeSys U standard control unit to be inserted in a power base LUB12 or LUB32 to form a TeSys U starter controller, for 3-phase motor applications up to 0.25kW@400V. It provides full protection for motors with a rated current Ir 0.35-1.4A (Ir adjustable), overload tripping class 10, short circuit at 13 x Irmax, overcurrent at 14.2 x Ir, phase loss, insulation fault (protection of equipment only). Control unit to be supplied with 24V DC through the control terminal block located in the power base. Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
