Matrox Monarch HDX Streaming and Record HDMI og SDI

Strøm og spill inn video fra SDI- og HDMI-kilder samtidig med Matrox Monarch HDX. Monarch HDX utvides på Monarch HD og legger SDI I / O til den allerede tilgjengelige HDMI I / O- og dobbeltkanal-operasjonen med uavhengige H.264-kodere. Denne funksjonaliteten gjør den egnet for kringkasting og andre profesjonelle arbeidsflyter som krever strømming og innspilling av innhold.Å ha diskrete kodere gjør det mulig for hver kanal å fungere separat. Du kan streame til to forskjellige lokasjoner, registrere proxy- og masterfiler fra samme inngang og registrere to innganger samtidig. Du kan også bruke den ene koderen for å streame video live, mens den andre koderen tar opp en kopi av sendingen av høy kvalitet for avspilling etter live-strømmen. Enten du bruker den til direkteavspilling eller innspilling, kan Monarch HDX integreres i SD- eller HD-produksjoner. HDMI Video Input 1920 x 1080p 60/59.94/50/30/29.97/25/24/23.981920 x 1080i 29.97/251280 x 720p 60/59.94/50HDMI Video Output Preview output of video input signal2-frame delay from input to outputSD video output as windowed in an HD outputSDI Video Input 1920 x 1080p 60/59.94/50/30/29.97/25/24/23.981920 x 1080PsF 29.97/251920 x 1080i 29.97/251280 x 720p 60/59.94/50720 x 576i 25720 x 486i 29.97SDI Video Output Clean distribution of SDI incoming signal0-frame latency passthrough of Input signalHardware bypass relay present in SDI signal path is "closed" on power failureAudio Input Processes first two channels of audio embedded in HDMI or SDI input signalsUnbalanced analog stereo input via 1/8" jack (3.5 mm)Line levelAudio Output Pass-through of 8 embedded audio channels in HDMI and SDI signalsUnbalanced analog stereo output via 1/8" jack (3.5 mm), pass-through of input Line levelFrame Synchronization On both HDMI and SDI inputs.Video Encoder Built-in H.264/MPEG-4 Part 10 (AVC)Resolutions Selectable encoding resolutions:128 x 128 to 1920 x 1080Video Bit Rates Single Encoder:Streaming mode - 20 MbpsRecording mode - 30 MbpsDual Encoder:Maximum 10 Mbps for streaming channelsMaximum 30 Mbps combining both channelsEncode Frame Rates Encode frame rates (fps): 60/50, 30/25/24, 15/12.5Note: The maximum encoded frame rate is 30 fps when input resolution is 1920 x 1080Encoding Profiles Baseline, Main, and HighEncoding Controls 2.0, 3.0, 3.1, 4.0, 4.1 level supportIBP GOP size and structureVariable bit rate supportAverage min/max data rate controlsDe-blocking filterAudio Encoder MPEG-4 AACAudio Encoding Standard: AAC-LCSample Frequency 32, 44.1, or 48 kHz when digitized from analog sourceChannels 2 channels stereo (L/R)Audio Bit Rates Range from 32 kbps to 256 kbpsNote: Audio codec settings are applied to streaming or files delivered by both encoders.Scaler High quality multi-tap 10-bit scaler and de-interlacerAvailable to both streaming and recording operationsPreview Stream format: H.264Bitrate: 300 kbps (average)Stream type: RTSPRecording Formats MP4 and MOV with two channels of embedded AAC audio (maximum file length of 300 minutes)Network Interface RJ45 connector providing 10/100/1000 Base-T Ethernet with Static or DHCP addressingProtocols:RTMP, RTSP/RTPIPv4 supportUnicast and Multi Unicast (from 3 to 10 clients)User Interface HTTP via standard PC or Mac web browser using Monarch HDX Command CenterFront panel push buttons for independent streaming and recording Start/Stop controlRecording Media Support 2x USB 2.0: Support for NTFS file system Monarch HD will support writing to USB 3.0 devices at USB 2.0 speeds1x SD card slot: Supports SD and SDHC cards Supports SDXC cards formatted with NTFSNetwork mapped drive: Support for writing to Shared Folders in computers found on a network using NFS or Windows share protocolsPower Line voltage: 100-240 VAC, 0.5 AFrequency: 50-60 HzInput: external AC/DC adapter -- IEC320-C8Output: 9 to 24 VDCTotal power consumption: 20 to 30 W typical, 42 W maxDIN4 locking power connectorDimensions 14.2 x 21.6 x 3.6 cm15.3 x 21.6 x 3.8 cm (including pads and BNC spigots)
