Savox SB 2262SG Servo 23Kg 0,08s HV Alu Brushless Steel Gear Low

SAVÖX SB2262SG - Monster Torque Low Profile Steel Gear Servo 0.08s/25kg @ 7.4VThe powerful "Monster" performance series servos from Savox utilize an all aluminum case, and unique brushless motor and controller technology to boost power up to 35% over previous generation servos.Features:Full Aluminum Case2 Precision Ball BearingsMetal GearsSpecifications:Torque @ 6.0v: 18kgSpeed @ 6.0v: 0.10s/60°Torque @ 7.4v: 25kg/cmSpeed @ 7.4v: 0.08s/60°Torque @ 8.4v: 32kg/cmSpeed @ 8.4v: 0.065s/60°Dimensions L x W x H: 40.8 x 20.2 x 25.75mmWeight: 62gTechnical Details:Operating Temperature: 14° - 122°F (-10° - 50°C)Running Current (no load): 180mA @6.0V, 200mA @7.4V, 220mA @8.4VStall Current (at locked): 4500mA @6.0V, 5600mA @7.4V, 6300mA @8.4VIdle Current: 5mA @6.0V, 5mA @7.4V, 5mA @8.4VWire Length: 300 +/- 5mmOutput Gear Spline: 25 ToothBearings: 2BBOperating Travel: 90° (1000 → 2000 µ second)Neutral Position: 1500 µ secondPulse Width Range: 800 → 2200 µ secondMaximum Travel: Appx 130° (900 → 2100 µ second)Refresh Rate: 333 HzMotor Type: Brushless
